Slim Profile Emergency Backup Driver And Battery – 7W – 30-60 VDC Output – BLD-YT08D-XXX

The BLD-YT08D-XXX emergency LED driver and battery works with LED drivers in commercial luminaires to keep them powered during emergency outages. When AC supply power is lost in the event of a power outage, the emergency driver switches on automatically to provide backup battery power directly to LED arrays at a rated output voltage of 30–60 VDC. The superior Li-ion battery provides backup light for a minimum of 90 minutes, with 10 times the shelf life of a traditional lead acid battery. The emergency battery and driver assembly are UL924 Listed and allow for both field and factory installations on suitable LED luminaires. The slim design of this kit is ideal for installation in tight spaces such as on troffers and light panels in recessed ceilings as well to accommodate a wider variety of installation types than more traditional emergency backup drivers/batteries with out sacrificing performance.

• Slim design allows installation in tighter spaces, ideal for troffers and light panels
• Housing constructed of durable galvanized steel
• Soft switching to prevent voltage spikes and increase longevity of the LED modules
• Operating temperature range of 32°–122° F
• Wide range input voltage – 100–347 VAC
• 30–60 VDC output
• 7 W max output, 133–260 mA output (relative to 30–60 VDC voltage)
• Rated IP20, suitable for damp locations
• Open/Short/Over-Voltage/Over Temperature protection
• UL924 Listed and meets CEC Title 20 standards
• 5 year warranty
