The 4ft LED Stairwell Fixture is designed for areas with low ceiling heights or in public corridors, stairwells, and utility areas. A curved, frosted polycarbonate lens diffuses the LEDs and creates a uniform 120° beam angle. Surface mount the corner light to the wall or ceiling using the included mounting hardware. Hardwire to power by using the 1/2“ trade size conduit knockouts. Select the desired wattage and color temperature using the switch on the inside of the fixture.
- White steel housing with a frosted polycarbonate lens
- 0-10V dimming
- Fixture has six 1/2“ trade size conduit knockouts
- Equivalent to a fixture with up to three 32W 4′ T8 tubes
- 120-277 VAC
- Certified by UL
- DLC 5.1 Standard
- 5-year warranty
| Ambient Operating Temperature | -20~+50 °C (-4~+122 °F) |
|---|---|
| IP Rating | IP20 |
| Warranty | 5 Year |
| UL File Number | E366643 |
| Shipping Exclusions and Details | Excluded From Free Shipping |
| Rated Life (L70) | 100000 Hours |
| Product Weight | 8lb 8.4oz (3.87kg) |
| Product Materials | Polycarbonate Lens, Steel Housing |
| Power Consumption | 35 Watts, 45 Watts, 55 Watts |
| Microwave Motion Sensor | None |
| Intensity | 4200 Lumens, 5400 Lumens, 6600 Lumens |
| Linkable | No |
| Lens | Frosted Polycarbonate |
| LED Color | Cool White, Natural White, Warm White, Selectable CCT |
| Integrated Surge Protection | 2 kV |
| Beam Angle | 120° |
| Input Connection Type | Pigtail |
| Finish | White |
| Equivalency | 3-lamp 32W T8 Tubes |
| Environmental Rating | Non-weatherproof, Suitable for Damp Locations |
| Efficacy | 120 lm/W |
| Dimming Type | 0-10V |
| Dimmable | Yes |
| Current Draw | 126/162/199 mA @ 277 VAC, 292/375/458 mA @ 120 VAC |
| CRI | 80+ |
| Certifications/Compliance | Certified by UL, DLC |
| CCT Value | 3500K, 4000K, 5000K |
| Brand | Super Bright LEDs |
| Wire Gauge | 18 AWG |
